The U-channel design keeps cables from sliding off. The perforated bottom lets heat escape. Our Perforated U-Channel Cable Tray gives you both benefits. The U-shaped sides hold the cables securely. The holes in the bottom keep them cool. This is a great combination for power cable installations. The cables stay in place. They stay at the right temperature. This extends their service life.
Holes in the Right Places
We place the holes carefully. The bottom has a matrix of holes. The holes are evenly spaced. They allow good airflow. Heat escapes from the tray. The holes also allow water to drain. No pooling on the tray. The side rails are solid. This keeps the cables contained. The holes do not weaken the tray. We design the hole pattern to preserve the structural strength. The tray carries its rated load without sagging. Under full load, the deflection stays under 1/200 of the span.
Available in Steel and Stainless Steel
The Perforated U-Channel Cable Tray is available in steel and stainless steel. Steel is the most common choice. It is strong and affordable. For outdoor use, we hot-dip galvanize the steel. The zinc coating is 65μm or thicker. For indoor use, powder coating is available. The coating is 60μm thick. Stainless steel is available for wet and corrosive environments. 304 is the standard grade. 316 is for coastal and chemical applications. All accessories match the tray material. Our 2-year warranty covers everything.
Product Specifications
|
Parameter |
Specifications / Options |
|
Width |
50, 100, 150, 200, 250, 300, 400, 500, 600, 800, 1000mm (custom up to 1200mm) |
|
Side Height |
25, 50, 100, 150, 200mm |
|
Standard Length |
2000mm, customizable to 3000/4000/6000mm |
|
Structure |
U-shaped side rails with perforated bottom. Matrix hole pattern. Solid side rails prevent cable slippage. |
|
Material & Finish |
Q235 Steel: Hot-dip galvanized (≥65μm, ≥480h salt spray) or Powder coating (≥60μm). Stainless Steel: 304 or 316L. |
|
Plate Thickness (Steel/SS) |
W≤150mm: 1.0mm; 150<W≤300: 1.2mm; 300<W≤500: 1.5mm; 500<W≤800: 2.5mm; W>800: 3.0mm |
|
Hole Pattern |
Matrix arrangement on bottom. Optimized for cooling and drainage. |
|
Load Performance |
Deflection ≤ Span / 200 at rated load. Meets JB/T 10216-2025 standard. |
|
Accessories |
90° bends, tees, crosses, reducers, end caps, U-channel splice plates, grounding clips, bolts, brackets, drop rods |
