Cables need full support across their entire length. Gaps underneath can cause problems. Small cables may sag into the gaps. Heavy cables may deform the tray over time. Our Solid Bottom Type Cable Tray gives you a continuous supporting surface. The bottom is completely solid. There are no holes, no slots, and no openings. Every cable rests on a smooth, flat surface. This protects the cables and extends their service life.
Reinforced for Strength
A solid bottom tray can be heavy. The extra material adds weight. But we build it to be strong. The side rails are reinforced with stiffening ribs. The bottom is pressed with strengthening channels. This gives the tray rigidity without making it too heavy. The tray carries its rated load without sagging. We test each batch. The deflection under full load stays under 1/200 of the span. This meets all standards. The tray is built to last for many years of service.
Applications That Need a Solid Bottom
This tray is used in many applications. Food processing plants need solid bottoms. They do not want crumbs or liquids falling through. Pharmaceutical factories also use this tray. They need clean surfaces that are easy to wipe down. The Solid Bottom Type Cable Tray is also used in areas with oil or chemical drips. The solid bottom catches the drips and protects the cables below. We offer this tray in steel, stainless steel, and aluminum. All accessories match the tray material. Our 2-year warranty covers the complete system.
Product Specifications
|
Parameter |
Specifications / Options |
|
Width |
50, 100, 150, 200, 250, 300, 400, 500, 600, 800, 1000mm (custom up to 1200mm) |
|
Side Height |
25, 50, 100, 150, 200mm |
|
Standard Length |
2000mm, customizable to 3000/4000/6000mm |
|
Structure |
Solid bottom tray with reinforced side rails. Pressed strengthening channels on bottom. No holes or openings. |
|
Material & Finish |
Q235 Carbon Steel: Powder coating (≥60μm) or Hot-dip galvanized (≥65μm, ≥480h salt spray). Stainless Steel: 304 or 316L. Aluminum: 6063, anodized (≥12μm). |
|
Plate Thickness (Steel/SS) |
W≤150mm: 1.0mm; 150<W≤300: 1.2mm; 300<W≤500: 1.5mm; 500<W≤800: 2.5mm; W>800: 3.0mm |
|
Plate Thickness (Aluminum) |
W≤150mm: 1.2mm; 150<W≤300: 1.5mm; 300<W≤500: 2.0mm; 500<W≤800: 2.5mm; W>800: 3.5mm |
|
Load Performance |
Deflection ≤ Span / 200 at rated load. Meets JB/T 10216-2025 standard. |
|
Accessories |
90° bends, tees, crosses, reducers, end caps, full cover plates, splice plates, grounding clips, bolts, brackets, drop rods |
