Perforated trays give you excellent ventilation. The holes let heat escape from cables. The open design also makes it easy to attach cable ties. But standard perforated trays can bend over long spans. The holes reduce the material strength. Our Large Span Perforated Cable Tray solves this problem. We use thicker material and add reinforcement to the bottom and side rails. You get the cooling benefits of a perforated tray with the strength needed for long spans.
Smart Hole Pattern and Strong Structure
The hole pattern on our tray is not random. We use a matrix pattern that minimizes stress concentration. Each hole is placed to avoid weakening the structural lines of the tray. The side rails are thicker than standard perforated trays. The bottom has reinforcing ribs between the hole rows. This design distributes the load evenly. The tray does not bend or sag. For spans of 6 meters or more, we recommend 2.0mm to 2.5mm thickness. The deflection under full load stays under 1/200 of the span. Your cables stay cool and properly supported.
Multiple Materials for Multiple Environments
We offer the Large Span Perforated Cable Tray in several materials. Q235 steel with hot-dip galvanizing is the most common choice for outdoor use. The zinc coating is 65μm or thicker. It passes 480 hours of salt spray testing. For indoor use, powder-coated steel gives a clean, professional look. Stainless steel is available for wet or corrosive environments. Aluminum is best when weight is a concern. All accessories match the tray material and finish. Splice plates, brackets, and supports are all reinforced for long-span performance. Our 2-year warranty and responsive support give you peace of mind.
Product Specifications
|
Parameter |
Specifications / Options |
|
Width |
50, 100, 150, 200, 250, 300, 400, 500, 600, 800, 1000mm (custom up to 1200mm) |
|
Side Height |
25, 50, 100, 150, 200mm |
|
Standard Length |
6000mm, customizable to 8000/10000/12000mm |
|
Structure |
Tray style with matrix perforated bottom. Reinforced side rails. Pressed-in ribs between hole rows. |
|
Material & Finish |
Q235 Carbon Steel: Hot-dip galvanized (≥65μm, ≥480h salt spray) or Powder coating (≥60μm). Stainless Steel: 304 or 316L. Aluminum: 6063-T6. |
|
Plate Thickness (Steel/SS) |
W≤150mm: 1.0mm; 150<W≤300: 1.2mm; 300<W≤500: 1.5mm; 500<W≤800: 2.5mm; W>800: 3.0mm |
|
Plate Thickness (Aluminum) |
W≤150mm: 1.2mm; 150<W≤300: 1.5mm; 300<W≤500: 2.0mm; 500<W≤800: 2.5mm; W>800: 3.5mm |
|
Hole Pattern |
Matrix arrangement. Optimized to minimize stress concentration. |
|
Load Performance |
Deflection ≤ Span / 200 at rated load. Suitable for spans up to 8m. |
|
Accessories |
90° bends, tees, crosses, reducers, end caps, splice plates, high-strength bolts, brackets, drop rods, span support braces |
