Some projects have many cables. They need wide trays. The standard widths may not be enough. Our Wide Span Cable Tray starts at 100mm and goes up to 1200mm. This range covers most applications. From telecom bundles to power distribution, we have the size you need. The tray is built to hold heavy loads across wide spans without sagging. This is important because wide trays are more likely to bend in the middle. Our design prevents that.
Strong Side Rails and Close Rung Spacing
We use thicker side rails on wide trays. The extra width creates more leverage on the structure. Thicker steel resists that leverage. For ladder trays, we space the rungs at 250mm instead of the standard 300mm. This is a small change, but it makes a big difference. More rungs mean the load is spread over more points. No single rung carries too much weight. The connection points between rungs and side rails get triangular reinforcement plates. This is our patented design. It stops weld cracks under heavy loads. We do not cut corners on wide trays because the consequences of failure are higher.
Proven Quality You Can Count On
Every Wide Span Cable Tray we produce goes through load testing. We test a sample from every batch. We apply the rated load and measure deflection. If any tray fails our internal standard, the whole batch gets re-inspected. This strict process ensures your wide cable tray works exactly as promised. We offer multiple finishes. Steel trays come galvanized or powder coated. Stainless steel and aluminum are also available. Our 2-year warranty gives you extra protection. We have supplied wide trays to major data centers, manufacturing plants, and power stations. You get the same quality they received.
Product Specifications
|
Parameter |
Specifications / Options |
|
Width |
100, 150, 200, 250, 300, 400, 500, 600, 800, 1000, 1200mm (custom available) |
|
Side Height |
25, 50, 100, 150, 200mm |
|
Standard Length |
2000mm, customizable to 3000/4000/6000mm |
|
Structure |
Ladder, Trough, or Tray. Integral stiffener. Ladder rung spacing: 250mm. Patented triangular reinforcement plates. |
|
Material & Finish |
Q235 Carbon Steel: Powder coating (≥60μm) or Hot-dip galvanized (≥65μm, ≥480h salt spray). Stainless Steel: 304 or 316L. Aluminum: 6063-T6. |
|
Plate Thickness (Steel/SS) |
W≤150mm: 1.0mm; 150<W≤300: 1.2mm; 300<W≤500: 1.5mm; 500<W≤800: 2.5mm; W>800: 3.0mm |
|
Plate Thickness (Aluminum) |
W≤150mm: 1.2mm; 150<W≤300: 1.5mm; 300<W≤500: 2.0mm; 500<W≤800: 2.5mm; W>800: 3.5mm |
|
Load Performance |
Tested per batch. Deflection ≤ Span / 200. |
|
Accessories |
90° bends, tees, crosses, reducers, end caps, reinforced splice plates, high-strength bolts, anti-vibration clamps, heavy-duty L-brackets, drop rods |
