Indoor cable trays need to look professional. They also need to resist dust and minor scratches. Our Powder Coated Perforated Cable Tray gives you both. The powder coating is a dry paint. We apply it with an electrostatic charge. Then we bake it in an oven. The coating bonds to the metal. It is tough and durable. It does not chip or scratch easily. The standard color is gray. We can also match custom colors.
Complete Coverage on Every Surface
We coat the entire tray. The outside gets coated. The inside gets coated. The edges get coated. The hole walls get coated. There is no bare metal anywhere. The coating is 60μm thick. This is thicker than standard liquid paint. It provides better protection. The coating is also smooth. Dust does not stick to it easily. Cleaning is simple. A quick wipe keeps the tray looking new. The coating also insulates the tray. This adds a small layer of electrical safety.
Ideal for Equipment Rooms and Workshops
The Powder Coated Perforated Cable Tray is a great choice for equipment rooms, data centers, and workshops. The perforated design provides cooling. The powder coating provides a clean appearance. The tray is available in standard widths and heights. We offer it in Q235 steel. Stainless steel is also available if you need more corrosion resistance. All accessories are powder coated to match. Splice plates, brackets, and drops rods all have the same finish. The color matches throughout the system. Our 2-year warranty backs every component.
Product Specifications
|
Parameter |
Specifications / Options |
|
Width |
50, 100, 150, 200, 250, 300, 400, 500, 600, 800, 1000mm (custom up to 1200mm) |
|
Side Height |
25, 50, 100, 150, 200mm |
|
Standard Length |
2000mm, customizable to 3000/4000/6000mm |
|
Structure |
Perforated tray with matrix hole pattern. Full powder coating on all surfaces including holes and edges. |
|
Material & Finish |
Q235 Carbon Steel: Electrostatic powder coating (≥60μm). Standard color: gray. Custom colors available. Stainless Steel: 304 or 316L also available. |
|
Plate Thickness (Steel) |
W≤150mm: 1.0mm; 150<W≤300: 1.2mm; 300<W≤500: 1.5mm; 500<W≤800: 2.5mm; W>800: 3.0mm |
|
Coating Properties |
Smooth finish. Dust-resistant. Easy to clean. Insulating. |
|
Load Performance |
Deflection ≤ Span / 200 at rated load. Meets JB/T 10216-2025 standard. |
|
Accessories |
90° bends, tees, crosses, reducers, end caps, splice plates, bolts, brackets, drop rods. All accessories powder coated to match. |
